Pellets
Pellets
Size
Height: 1,101 mm
Width: 534 mm
Depth: 540 mm
Colors
Black paint
(Selected)
Corten
(Selected)
-
Height 1101 mm
-
Width 534 mm
-
Depth 540 mm
-
Weight 125 kg
-
Flue outlet Ø 80 mm
-
Flue exit options Rear
Specifications
-
Nom output 10.3 kW
-
Efficiency 91%
-
Heating capacity cubic up to 350 m³
-
CO Emission 0.01%
-
Dust Product Emission 18 mg/Nm³
-
NOx Emission 127 mg/Nm³
-
OGC Emission 1 mg/Nm³
-
Closed combustion Yes
-
Clean burn Yes
-
External air intake Yes
-
Ash solution Yes
Installation- and User Manual
(5.43 MB)
Exploded view and spareparts
(1.67 MB)
Ecolabel
(267.94 KB)
Ecolabel datasheet
(896.61 KB)
Test certificate
(2.11 MB)
Declaration of Performance
(970.09 KB)
Declaration of Conformity
(373.14 KB)
